SMDR with AP00 Programming (PN-AP00-B with AP00 program) (2)
For local office or tandem office, in addition to the programming of SMDR with AP00 programming (PN-
AP00-B with AP00 program), do the following programming. For details of the SMDR with AP00 pro-
gramming (PN-AP00-B with AP00 program), refer to Station Message Detail Recording (SMDR) of Fea-
ture Programming Manual.
DESCRIPTION DATA
Not provide the system with MP built-in
SMDR.
NOTE: Do not assign CM40 Y=00>14
when using MP built-in SMDR in
Local Office of Centralized Billing-
CCIS.
(1)
(2)
800
1: Not provided
(AP00 is effective)
Not provide the system with Centralized Bill-
ing-CCIS for Center Office.
(1)
(2)
368
1: Not provided
Provide the system with Centralized Billing-
CCIS for Local Office.
(1)
(2)
378
0: To provide
Specify whether the calling party information
(Trunk Route No./Station No.) is sent to
SMDR on CCIS tandem calls.
See Example 2: Data Assignment of SMDR
Call Record on a Tandem Call through
CCIS. Page 225
(1)
(2)
377
0 : Station No. and Office No.
1 : Trunk Route No.
START
CM08
INITIAL
A
CENTRALIZED BILLING-CCIS
To Next Page
