CHAPTER 3 SYSTEM DATA PROGRAMMING
– 216 – NWA-008853-001 Rev.3.0
97ch3003.fm
DESCRIPTION DATA
Provide SMDR service for outgoing calls to
the required trunk route.
•
(1)
(2)
Y=14
00-63: Trunk Route No.
1: To provide
Assign a trunk access code sent to SMDR for
outgoing calls.
•
(1)
(2)
Y=44
00-63: Trunk Route No.
00-99: Trunk Access Code
Provide SMDR service for incoming calls to
the required trunk routes.
•
(1)
(2)
Y=49
00-63: Trunk Route No.
0: To provide
Specify the direction for sending detail infor-
mation on tandem calls from Local Office.
(1)
(2)
2: Send detail information of tandem call to
SMDR
0: Not sent
1: To send
For local office to SMDR, specify the buffer-
ing method when the number of the stored
SMDR information has reached to the prede-
termined value.
(1)
(2)
7
0 : New data is stored by deleting the old-
est data
1 : No new data is stored
Specify whether account code is sent in the
Authorization Code Area of Call Record for
tandem calls.
(1)
(2)
170
0: Not sent
1 : To send
Specify whether the access code is added in
Call Record.
(1)
(2)
171
0 : Not added
1: To add
Specify whether DID number is set in destina-
tion number area of Call Record.
(1)
(2)
172
0: To set
1 : Not set
Specify whether ANI for local office is sent to
SMDR.
NOTE: CMDD00>173 is not available for
the extended NEAX 2400 IMS For-
mat.
(1)
(2)
173
0: Not sent
1 : To send
C
CM35
CMDD00
D
JANUARY/31/2006
CENTRALIZED BILLING-CCIS
