CHAPTER 3 SYSTEM DATA PROGRAMMING
– 252 – NWA-008853-001 Rev.3.0
97ch3004.fm
Programming
DESCRIPTION DATA
Assign fault kind information and its external
alarm kind.
Fault Kind number:
01 : System Initialization
04 : MP-FP/AP communication failure
08 : FP/AP card down
09 : Power failure
12 : CS/ZT fault occurred
16 : Periodic maintenance
20 : DTI Line failure
21 : DCH/BRT/PRT D-channel link connec-
tion failure
22 : CCH/IPT link connection failure
24 : Number of faulty trunks was more than
predetermined number
25 : Number of lockout stations was more
than predetermined number
26 : DLC card down
27 : Synchronism of DPC missed
28 : SMDR output buffer memory overflow
2B: CS/ZT fault occurred
18 : FP/AP card returned to normal condition
19 : Power failure returned to normal condi-
tion
30 : DTI Line returned to normal condition
31 : DCH/BRT/PRT D-channel link connec-
tion returned to the normal condition
32 : CCH/IPT link connection returned to nor-
mal condition
34 : Number of faulty trunks was less than
predetermined number
35 : Number of lockout stations restored to
less than predetermined number
36 : DLC card returned to normal condition
37 : Synchronism of DPC returned to normal
condition
38 : SMDR output buffer memory returned to
normal condition
3B: CS/ZT returned to normal condition
•
(1)
(2)
Y=2
Fault Kind No.: See left column
External Alarm Kind
0: Fault Memory/No out put of External
Alarm
1: Fault Memory/External Alarm is MN
alarm
2: Fault Memory/External Alarm is MJ
alarm
3: Fault Memory/External Alarm Kind is
determined in standard data
NONE : No fault memory store/
No External Alarm output
START
CMEA
A
CENTRALIZED MAT-CCIS
