DESCRIPTION DATA
Assign the paging function to the DK card or
external equipment interface on the MP card.
(1)
(2)
XX Y
XX: 00-31 (DK Card No. assigned by
CM10/CM14 [E800-E831])
Y : 0-3 (Circuit No. of DK card)
313: Built-in External Equipment Interface
02 XX: Speak Paging start
XX : 00-09 (Speaker Paging Zone 0-9)
Specify the conditions for paging access. (1)
(2)
094: Paging Access Tone
0: To send
1: Not sent out
Assign the access code for paging access. •
(1)
(2)
Y=0-3 Numbering Plan Group 0-3
X-XXXX: Access Code
100-163: For Paging Access
(Route 00-63)
Assign paging trunk route to the trunk number
assigned by CM10/CM14.
•
(1)
(2)
Y=00 Trunk Route Allocation
000-254: Trunk No.
00-63: Trunk Route No.
Assign Paging Answer Zone and Kind of Pag-
ing to the trunk number assigned by CM10/
CM14.
•
(1)
(2)
Y=28 Zone/Kind of Paging
000-254: Trunk No.
X Z
X: 0-9 (Paging Answer Zone 0-9)
Z: 0 (No answer)
Specify the trunk route assigned by CM30
Y=00 as a paging trunk route.
•
(1)
(2)
Y=00
00-63: Trunk Route No.
05: Paging Trunk
•
(1)
(2)
Y=08 Dial Pulse Sending Capability
00-63: Trunk Route No.
1: No Dial Pulse is sent out
Specify the combination of trunk routes allow-
ing a Tandem connection.
•
(1)
(2)
Y=0
XX ZZ
XX: 00-63 (Incoming Trunk Route for
CCIS)
ZZ : 00-63 (Outgoing Paging Trunk
Route)
0: Allow
A
CM44
CM08
CM20
CM30
CM35
CM36
END
PAGING ACCESS-CCIS
