Lamp Indications
Switch Settings
LAMP
NAME
COLOR FUNCTION
RUN Green Flashes at 120 IPM while this card is operating normally.
L0-L3 Green Second data setting value for CMD001 > 250
0 1 (port0)-3 (port2)
L3 Indication of transmitting
status of port0
Indication of CTS signal status on
port0-2
L2 Indication of transmitting
status of port1
Indication of DCD signal status on
port0-2
L1 Indication of transmitting
status of port2
Indication of TXD signal status on
port0-2
L0 Indication of transmitting
status of port3
Indication of RXD signal status on
port0-2
SWITCH NAME
SWITCH
NUMBER
SETTING
POSITION
FUNCTION CHECK
SENSE
(Rotary SW)
NOTE 1
0-3 Not used
4-F Set the switch to match the AP Number (04-31) to be
set by CM05.
MB (Toggle SW)
NOTE 2
UP For make-busy
For normal operation
Continued on next page
F
4
AP No.
SW1-4: ON
04 05 06 07 08 09 10 11 12 13 14 15
SW1-4: OFF
20 21 22 23 24 25 26 27 28 29 30 31
SW No.
456789ABCDEF
ON
DOWN
PN-AP00-B (AP00)
To Next Page
