• CS55 DECT 6.0 technology
• CS70N DECT 6.0 technology
• CS351N DECT 6.0 technology
• CS361N DECT 6.0 technology
• Voyager 510 Bluetooth technology
Some of the above models are sold with and without the Plantronics Handset Lifter.
Refer to www.plantronics.com for details.
The SL1100 Telephone must be equipped with the NEC WHA (Wireless Headset Adapter – P/N
1091054).
5.10 Installing the ITX-1DE-1W(BK) TEL (V5.0 or higher)
5.10.1 Connecting the Phone
The following SIP phone is available in the SL1100 system.
5.10.2 Location of Controls
Front View
1
2
3
4
5
6
7
8
9
1012131415 11
Figure 2-120 SIP Phone - Front View
SL1100
ISSUE 5.0
2-84 Installation
