2.3 Optional Interface Cards
2.3.1 IP4WW-VOIPDB-C1
The VOIPDB-C1 card provides the RTP/RTCP voice
processing function.
• Mount this card onto the CPU card (VoIPDB slot) at Main
KSU.
• Max. 32 channels by license control.
2.3.2 IP4WW-CFVMS-C1/IP4WW-CFVML-C1
Two types of VRS/VM CF cards are available:
• Install into the VMDB mounted on the CPU card at Main
KSU.
• CFVMS: VRS and 2-channel InMail (Approx. 15 hours)
• CFVML: VRS and 4-channel InMail (Approx. 40 hours)
2.4 Multiline Telephones and Optional Equipment
2.4.1 IP4WW-12TXH-B TEL
The 12TXH-B TEL is a 2-wire digital multiline telephone
featuring:
• Programmable keys: 12
• Soft Keys: 4
• LCD: 24 digits x 3 lines with Backlit
• Handsfree: Full-duplex
• Backlit dial pad: Yes
• Angle Adjustment: 2-steps
• Wall-Mounting kit: Built-in
2.4.2 IP4WW-24TXH-B TEL
The 24TXH-B TEL is a 2-wire digital multiline telephone
featuring:
• Programmable keys: 24
• Soft Keys: 4
• LCD: 24 digits x 3 lines with Backlit
• Handsfree: Full-duplex
• Backlit dial pad: Yes
• Angle Adjustment: 2-steps
• Wall-Mounting kit: Built-in
