NEC SL1100 - Figure 4-2 Removing the Main-Cover; Figure 4-3 Exchanging the Fuse

3. Loosen two screws and remove the Main-Cover.
Two screws
Hooks
Main-Cover
Figure 4-2 Removing the Main-Cover
4. Exchange the fuse (250 V/8 A) on 084M-B1 PCB.
< Top View >
084M-B1
FUSE (8 A / 250 V)
Figure 4-3 Exchanging the Fuse
SL1100 ISSUE 5.0
4-2 Maintenance
