NEC SL1100 - Specifications

Items 1 KSU
(1228)
2 KSU
(2456)
3 KSU
(3684)
4 KSU
(48112)
(V3.5
Added)
*1
Description Note
Station Port Max. 28 56 84 112 1KSU: 084M+080Ex2
2KSU: 084Mx2+080Ex4
3KSU: 084Mx3+080Ex6
4KSU: 084Mx4+080Ex8 (V3.5)
Station
Port
2W Key Set 24 48 72 96 Max. 24/KSU
084M+080Ex2
SLT (–28V) 20 40 60 80 1KSU: 084M+008Ex2
2KSU: 084Mx2+008Ex6
3KSU: 084Mx3+008Ex9
4KSU: 084Mx4+008Ex8 (V3.5)
2W DSS
Console
12 Connect to digital extension Port
at 084M/080E
Doorphone 2 4 6 6 2DPH I/F on 084M (analog exten-
sion port 3, 4)
Alternative use with SLT
SIP-MLT/
SIP Std.
terminal
64
VM/VRS
Channels
2 VM ports/ 4 VRS ports (default)
(Total Max.16)
CFVMS-C1
Port increased by license.
4 VM ports/ 4 VRS ports (default)
(Total Max.16)
CFVML-C1
Port increased by license.
Virtual Extension 50
Relay 2 4 6 6 2 circuits on 084M
Power Failure Transfer 3 6 9 12 1 PFT circuit on 4COIDB (COI
port 1 and PF port)
External Paging (Audio
Out)
1 2 3 3 1 audio-In/Out and 2 audio-In cir-
cuits on 084M.
Select one of 084M for MOH/
BGM.
External MOH (Audio In) 1
External BGM (Audio In) 1
Ethernet Port 1 1 circuit on CPU
Built-In Answering Ma-
chine Channel
2 2 circuits on CPU
VoIP Channels 32 Port increased by license.
V.34 Modem 1 1 circuit on CPU-B1 (VMDB)
Conference Circuits 32 (Max. 16 parties per Conference)
DSP Resource
*2
32 For 1228M KSU (DSP on CPU)
- 32 64 128 For 1228ME EXP 32ch DSP on
each EXIFE-C1
DSP Sender
*3
128
*1. Lot D or higher Main KSU or FPGA Version 0100 and V3.5 or higher System Software required. FPGA
version can be found in PC Pro/Web Pro and Lot # is on side of Chassis.
• To verify if your Chassis is D or higher check the lot # (e.g. 118DCA-G). The 4th Character needs to be D or
higher.
• To verify the FPGA version connect with PC Pro/Web Pro and check version information in the blade
configuration screen.
*2. Service Tone receiver, DTMF receiver, Caller ID sender / receiver, MF receiver, MFC receiver
*3. Service Tone sender, DTMF sender, MF sender, MFC sender
SL1100 ISSUE 5.0
5-2 Specifications
