NEC SL1100 - Figure 2-54 Removing the Front Cover; Figure 2-55 Disconnecting the Battery Connection Cable

2. Loosen two screws and remove the Front Cover.
Front Cover
Two screws
(with stopper)
Figure 2-54 Removing the Front Cover
3. Disconnect the Battery connection cable from the Fuse Unit.
Battery Connection Cable
Fuse Unit
Figure 2-55 Disconnecting the Battery Connection Cable
SL1100 ISSUE 5.0
2-38 Installation
