NEC SL1100 - Figure 9-6 DR700 Encryption; Table 9-2 DR700 Supported Encryption

Issue 6.0 NEC SL1100
9 - 22 IP Multiline Station (SIP)
Encryption
The SL1100 Supports AES 128-bit encryption between DR700 terminals and
the VoIPDB.
Table 9-2 DR700 Supported Encryption
Source
Destination SRTP Comment
DR700 SDT SIP (P2P) N
DR700 STD SIP (Non P2P) S
The encryption will be between the IP terminal and
the VoIPDB. Once the voice leaves the SL1100 to
third party SIP terminal the voice cannot be
encrypted.
DR700 DR700 S
DR700 PSTN S
The encryption will be between the IP terminal and
the VoIPDB. Once the voice leaves the SL1100 to
the public network it cannot be encrypted.
DR700 IP Network (SIP) S
The encryption will be between the IP terminal and
the VoIPDB. Once the voice leaves the SL1100 to
the SIP network it cannot be encrypted.
DR700
Encryption
On
DR700 Encryption Off N‘
S = Supported N = Not Supported
Figure 9-6 DR700 Encryption
DR700
DR700
DR700
DR700
