NEC SL1100 Issue 6.0
Networking Manual 9 - 67
13.10.3 Manual Registration
Steps 1~4 are the same as for Section 13.10.2 Automatic
Registration on page 9-63.
1. Same as for Automatic Registration Mode.
2. Same as for Automatic Registration Mode.
3. Same as for Automatic Registration Mode.
4. Same as for Automatic Registration Mode.
5. Program10-46 – ChangeProgram10-46-01 to Manual.
6. Same as for Automatic Registration Mode.
7. Same as for Automatic Registration Mode.
8. The SIP MLT Station requires assignments to be made in the
phone itself. Enter the Program Mode in the station using the
following steps.

The station does not require an Ethernet connection to enter the
program mode. Only power is required. Power can be provided
by an AC adapter plugged into the phone or by POE provided by
a data switch. If the data switch is providing POE it must be using
the 802.3AF standard.
For Basic bench testing only the following assignments are
required.
Figure 9-35 DR700 Server Information Setup
