Issue 6.0 NEC SL1100
12 - 2 All DSP Busy Indication
Alarm Report Example:
The report example below shows an alarm for all busy Station and Trunk DSPs.
LCD Display
SECTION 2 SERVICE CONDITIONS
When using IP Phones, the alarm is shown on both terminals involved in that
call if they are both on the same system.
The alarm cannot be displayed on Standard SIP Phones or Single Line phones.
If a call from a Standard SIP telephone to a Multiline telephone cannot be
established due to an All DSP Busy condition, the Multiline telephone will not
display the “All DSP” busy message.
If a SIP trunk call is sent to the SL1100 when all DSP resources are busy, the
call is rejected but the alarm is not displayed on any system telephone.
The default alarm setting is Minor.
<< ALARM REPORT >> 01/22/2009 23:37
LVL NO STAT DATE TIME ITEM UNIT SLT PRT PARAMETER
-------------------------------------------------------------------------------
MAJ 0068 ERR 01/22/09 09:30 VoIP All DSP Busy VoIPDB 01 00 STA
MAJ 0068 ERR 01/22/09 09:31 VoIP All DSP Busy VoIPDB 01 00 TRK
MIN 0002 REC 01/22/09 09:32 PKG Installation PRIU 02 00
LCD Display Indication Note
Clock/Calendar
XX = Slot number of CPU with VoIPDB.
VoIP All Busy XX
Soft Key
To Next Page
