Issue 6.0 NEC SL1100
9 - 36 IP Multiline Station (SIP)
Command 84-23 requires a Hexadecimal representation of the 8 bit ToS field.
For example, to assign the signaling packets an IP precedence value of 4 and
the voice packets an IP precedence value of 5, it would be as follows. Refer to
Figure 9-19 SIP MLT Basic Setup.
80 in Hex is 10000000 - This represents the signaling packets leaving
the IP phone
A0 in Hex is 10100000 - This represents the voice packets leaving the IP
phone
Figure 9-19 SIP MLT Basic Setup
