Issue 6.0 NEC SL1100
3 - 2 IP Networking
2.1 Configure IP Trunks
When installing a VoIP daughter board in the NEC SL1100 system, external line
ports are allotted in accordance with the number of Licensed ports for the
particular IP Application.
The NEC SL1100 system now has the required information about the remote
destinations and the
SIP configuration is complete. The only remaining task is
to configure F-Route to route calls to remote destinations via the IP trunks.
F-Route configuration is discussed in detail in the Automatic Route Selection
(ARS) feature in the NEC SL1100 Programming Manual.
Figure 3-1 Example of SL1100 IP Network Configuration
