NEC SL1100 Issue 6.0
Networking Manual 13 - 37
Centralized VM
In the example below site A will be using an InMail with 16 ports as the Centralized
VM. The InMail will use station ports 69 ~ 84 and have a pilot number of 100.
10-27-01 Set system ID 1 =
10.0.0.10
Set System ID 1 =
172.16.0.10
Define the IP Address of the destination
system.
System ID 1 was used because this was
the ID assigned in PRG 11-01-03.
20-01-04 3 3 Allows the sites to see BLF status of
extensions across the network.
10-20-01 Device Type 4 = Default Device Type 4 = Default Verify that both sites still have the default
value of 30000 assigned.
Port numbers other than default can be
used but all sites must use the same port
number.
Program Site A Site B Notes
Program Site A Site B Notes
47-01-17 69 NA Assign the InMail ports to 69 ~ 84
11-02-01 Default Verify the InMail extension numbers are
169 ~ 184
11-07-01 Group 32 = 100 NA Assign the VM pilot Number to group 32
15-03-01 Ext’s 169 ~ 184 = DP NA Change ALL VM extensions to DP
15-03-03 Ext’s 169 ~ 184 = Special NA Change ALL VM extensions to special
16-01-02 Group 32 = Priority NA Change VM groups calling cycle
16-01-04 Group 32 = Circular NA Change VM groups hunting mode
16-01-10 Group 32 = BNA NA Change VM groups enhanced hunting
16-02-01 Ext’s 169 ~ 184 = Group
32
NA Assign ALL VM extensions to the VM
group
16-02-02 Change the 1
st
VM ext
(169) to Priority 1, 2
nd
to
Priority 2, etc, etc
NA Assign the priority to ALL VM extensions.
45-01-01 DO NOT ASSIGN DO NOT ASSIGN Leave this Unassigned when using
Centralized VM
45-01-07 100 100 Assign the VM pilot number to ALL sites
45-01-08 32 NA Assign the VM department group only in
the site with the VM
45-01-10 ON ON Enable NSL protocol on ALL sites
84-12-31 RFC2833 RFC2833 Set all sites in the network to RFC2833.
