5. Description of Screen and Menu
PROGRAMMABLE AC POWER SOURCE
224
5.2.3 Menus of the Simulation Function
The menus of the Simulation function are shown in Table 5-7. You can open each menu by using a
soft-key. For how to use the Simulation function, see 4.3.
Table 5-7 Menus of the Simulation Function
Menu Description
Simulation Edit Osc Range Switches the output voltage range.
Misc Time Unit Switches the time unit between ms and s.
Trig Out Sets the trigger output.
File Store Saves to, clears, and renames the Simulation
Memory.
Recall Recalls the Simulation Memory.
Clear Resets the edited simulation to the factory default
settings.
Compile Compiles the edited simulation and moves to the
Simulation Control View.
Simulation Control Start Starts the simulation. It is displayed in the output
on and simulation stopped states.
Stop Ends the simulation. It is displayed in the
Simulation running state.
Measure Makes the measured value display settings. It is
displayed in the simulation stopped state.
Edit Moves to the Simulation Edit View. It is displayed
in the output off state.
5.2.4 Menus of the Memory Function
The menus of the Memory function are shown in Table 5-8. For how to use the Memory function,
see 4.8.
Table 5-8 Menus of the Memory Function
Menu Description
Setting Store Saves to, clears, and renames the Basic Setting Memory.
Setting Recall Recalls the Basic Setting Memory.
ARB Copy Copies the arbitrary waveform data between the internal memory and the USB
memory, and clears and renames it.
SEQ Store Saves to, clears, and renames the Sequence Memory.
SEQ Recall Recalls the Sequence Memory.
SIM Store Saves to, clears, and renames the Simulation Memory.
SIM Recall Recalls the Simulation Memory.
