NF DP Series - Table 3-1 Component Name (Front)

3.1 Component Name
DP Series/DP Series Type R
41
Table 3-1 Component Name (Front)
Number Name Description Refer to
1 Control panel Configures the settings and turns the
output on or off. Information such as
setting values and measured values is
displayed on the LCD screen.
3.1.3
2 Remote controller
connector
Optional remote controller can be
connected.
7.1
3 USB memory connector USB memory can be connected.
4.9
4 Front grill The fresh air inlet. An air filter is
attached.
9.2
5 Front grill holder Clasps for fixing the front grill.
9.2
6 Outlet
(Only for the single-phase
model)
Can provide up to 15 A of AC output per
outlet.
2.5
7 Power switch Turns the power on/off.
3.2
8 Caster Caster with the freely movable
front-wheels and fixed rear-wheels. Can
be used to move this product in the
horizontal location.
2.3
9 Adjuster Foot Can be used to fix this product
temporarily in the horizontal location.
2.2
10 Phase configuration setting
switch
(Multi-phase model only)
Set the output phase configuration.
3.2.2
