Table 2-3 Heat Value of DP series Type R
Model Rated output Heat value
Single-phase
DP015RS
Power running 1.5 kVA 0.5 kW 430 kcal/h
Reverse power flow
50 % 0.9 kW 780 kcal/h
100 % 1.7 kW 1470 kcal/h
DP030RS
Power running 3 kVA 0.9 kW 780 kcal/h
Reverse power flow
50 % 1.8 kW 1550 kcal/h
100 % 3.3 kW 2840 kcal/h
DP045RS
Power running 4.5 kVA 1.4 kW 1210 kcal/h
Reverse power flow
50 % 2.7 kW 2330 kcal/h
100 % 4.9 kW 4220 kcal/h
DP060RS
Power running 6 kVA 1.8 kW 1550 kcal/h
Reverse power flow
50 % 3.5 kW 3010 kcal/h
100 % 6.5 kW 5590 kcal/h
DP075RS
Power running 7.5 kVA 2.3 kW 1980 kcal/h
Reverse power flow
50 % 4.4 kW 3790 kcal/h
100 % 8.1 kW 6970 kcal/h
DP090RS
Power running 9 kVA 2.7 kW 2320 kcal/h
Reverse power flow
50 % 5.2 kW 4480 kcal/h
100 % 9.7 kW 8340 kcal/h
Single-phase
three-wire
DP030RD
Power running 3 kVA 0.9 kW 780 kcal/h
Reverse power flow
50 % 1.8 kW 1550 kcal/h
100 % 3.3 kW 2840 kcal/h
DP060RD
Power running 6 kVA 1.8 kW 1550 kcal/h
Reverse power flow
50 % 3.5 kW 3010 kcal/h
100 % 6.5 kW 5590 kcal/h
DP090RD
Power running 9 kVA 2.7 kW 2320 kcal/h
Reverse power flow
50 % 5.2 kW 4480 kcal/h
100 % 9.7 kW 8340 kcal/h
Three-phase
DP045RT
Power running 4.5 kVA 1.4 kW 1210 kcal/h
Reverse power flow
50 % 2.7 kW 2330 kcal/h
100 % 4.9 kW 4220 kcal/h
DP090RT
Power running 9 kVA 2.7 kW 2320 kcal/h
Reverse power flow
50 % 5.2 kW 4480 kcal/h
100 % 9.7 kW 8340 kcal/h
Note: Estimate at power input single-phase 200 V or three-phase three-wire 200 V or
three-phase four-wire 380 V (phase voltage 220 V), rated output.
