10.5 AC Output
DP Series/DP Series Type R
271
10.5 AC Output
[V]=Vrms, [A]=Arms, unless otherwise noted.
Single-phase model and Single-phase output of Multi-phase model
DP series
015S 030S
045S
045M
060S 075S
090S
090M
105S 120S
DP series Type R 015RS 030RS 045RS 060RS 075RS 090RS
Mode Single-phase two-wire
Floating output, the Lo terminal can be grounded.
Setting mode *1 Balanced mode, Unbalanced mode
Rated output voltage 100 V / 200 V
Voltage setting range
*2
Phase voltage setting (for all phases in balanced mode and each phase in
unbalanced mode)
0.0 V to 160.0 V / 0.0 V to 320.0 V
0.0 Vp-p to 454.0 Vp-p / 0.0 Vp-p to 908.0 Vp-p (arbitrary wave)
Line voltage setting (balanced mode and sine wave only)
0.0 V to 320.0 V / 0.0 V to 640.0 V (1P3W)
0.0 V to 277.2 V / 0.0 V to 554.2 V (3P4W)
Setting resolution Phase voltage setting: 0.1 V, Line voltage setting: 0.2 V
Voltage accuracy *3
(0.5 % of set + 0.6 V / 1.2 V)
Maximum current *4
Maximum peak
current *5
Peak value (Apk) which is four times of the maximum current
Reverse power flow
(only for Type R) *6
40 % (continuous, 30 °C to 40 °C) of maximum current (phase current, RMS)
50 % (continuous, lower than 30 °C) of maximum current (phase current, RMS)
100 % (reverse power flow time 180 s, reverse power flow duty 0.2, 40 °C or
lower) of maximum current (phase current, RMS)
Power capacity *7
1.5 kVA 3 kVA 4.5 kVA 6 kVA 7.5 kVA 9 kVA 10.5kVA 12 kVA
Load power factor DP series
0 to 1 (Phase lead or phase lag, 45 Hz to 65 Hz, external power injection or
regeneration are not available.)
DP series Type R
−1 to +1 (Phase lead or phase lag, 45 Hz to 65 Hz)
Frequency
setting range
40.00 Hz to 550.00 Hz (AC mode)
1.00 Hz to 550.00 Hz (ACDC mode)
Setting resolution 0.01 Hz
Frequency accuracy
0.01 % of set (23 °C
5 °C)
Frequency stability*8
0.005 %
Voltage frequency
characteristic *9
Output waveform sine wave, arbitrary wave (16 types), clipped sine wave (3 types)
Output on phase
setting range *10
0.0° to 359.9° variable
Setting resolution 0.1°
Output off phase
setting range *10
0.0° to 359.9° variable (active/inactive selectable)
Setting resolution 0.1°
Phase angle
setting range *1
(Unbalanced mode)
L2 phase: 0° to 359.9° (1P3W)
L2 phase: 0° to 359.9°, L3 phase: 0° to 359.9° (3P4W)
Setting resolution 0.1°
Phase angle accuracy
*11
45 Hz to 65 Hz:
1.0°
40 Hz to 550 Hz: 2.0°
DC offset *12
Within 20 mV (typ., fine adjustment available.)
*1: Only when polyphase system is configured with single-phase model.
*2: Line voltage setting only when polyphase system is configured with single-phase model.
