7.5 Power Cable
DP Series/DP Series Type R
243
7.5 Power Cable
Cables for the power input. They vary in cross sectional area depending on the power input and the
rated output as shown in Table 7-3. A crimp-type terminal is attached to each cable on the end which
is to be connected to the input terminal of this product. The length of the cable is 3 m.
 On the power cable, the end which is to be connected to the distribution board has no terminal
attached. Use a crimp-type terminal appropriate for the terminal screw diameter of the
distribution board to connect the cable firmly.
 The power cable is dedicated only to this product. Do not use it with any other product.
Table 7-3 Power Cable Model Names
Model name Power input Rated output
Maximum
power
consumption
Terminal
size
Nominal cross
sectional area
PA-001-3251 Single-phase
input
(1P2W)
1.5 kVA 2.25 kVA M6 5.5 mm
2
approx
PA-001-3252 3.0 kVA 4.50 kVA 14 mm
2
approx
4.5 kVA 6.75 kVA
6.0 kVA 9.00 kVA
PA-001-3253 7.5 kVA 11.25 kVA M8 22 mm
2
approx
9.0 kVA 13.50 kVA
PA-001-3254 10.5 kVA 15.75 kVA 38 mm
2
approx
12.0 kVA 18.00 kVA
PA-001-3255 Three-phase
three-wire
input
(3P3W)
4.5 kVA 6.75 kVA M6 5.5 mm
2
approx
PA-001-3256 6.0 kVA 9.00 kVA 14 mm
2
approx
7.5 kVA 11.25 kVA
9.0 kVA 13.50 kVA
PA-001-3257 10.5 kVA 15.75 kVA 22 mm
2
approx
12.0 kVA 18.00 kVA
PA-001-3263 Three-phase
four-wire
input
(3P4W)
4.5 kVA 6.75 kVA 5.5 mm
2
approx
6.0 kVA 9.00 kVA
PA-001-3264 7.5 kVA 11.25 kVA 14 mm
2
approx
9.0 kVA 13.50 kVA
10.5 kVA 15.75 kVA
12.0 kVA 18.00 kVA
