10. Specifications
PROGRAMMABLE AC POWER SOURCE
294
10.24 Memory Function
You can save basic settings (AC/DC mode, signal source, output range, AC setting, DC setting,
current limiter, setting range limit, etc.) for each output phase configuration in the non-volatile
Basic Setting Memory of No.1 to No.30, and recall them to use when the output is off. The No.1
setting is restored at power-on. The No.0 setting includes the setting items for the factory default.
The external control, display, and other settings are saved in non-volatile System Setting Memory
when they are changed by the panel operation or remote command.
The Sequence, Simulation, clipped sine wave, and arbitrary wave are saved in their own
non-volatile memories.
Items in the Basic Setting Memory
*73
Factory default
Output range 100 V range
AC/DC mode AC mode
Signal source INT
External synchronization signal (LINE or EXT) LINE
AC voltage setting 0 V
Frequency 50 Hz
Output waveform Sine wave
Output on phase and output off phase 0.0°
Phase voltage/Line voltage setting selection Phase voltage
Phase angle setting Single-phase three-wire: 180°
Three-phase four-wire: 120°, 240°
Balanced/Unbalanced Balanced
DC voltage setting 0 V
Current limiter
See 10.13
Setting range limit
See 10.14
External input gain 100 / 200
*73: Some items do not exist depending on the AC/DC mode or signal source.
Items in the System Setting Memory
Factory default
Output function Continuous
DC offset setting 0 mV
Measurement display mode Normal View
Measurement unit selection rms
Power unit energization setting All enabled (energization)
Remote sensing Off
AGC Off
General function
See 10.23 (excluding the time unit setting of the
Step Time for the Sequence and Simulation)
Monitor output target Current (L1 phase)
External interface USB
External control Disabled
