2.5 Output and System Cable Connection
Before connecting, check the followings.
 Before touching the output terminal, be sure to turn off the power switch of this product, and cut
the power to the distribution board. Otherwise, an electric shock might occur.
 The output terminals that can be grounded are the Lo or N terminals. Do not ground the Hi, L1,
L2, and L3 terminals.
About output terminal
Table 2-9 Output Terminals
DP series
DP015S, DP030S, DP045S, DP060S
DP030D, DP060D, DP090D, DP120D,
DP045T, DP090T,
DP090M (polyphase output)
DP075S, DP090S,
DP105S, DP120S,
DP090M (single-phase output)
DP series Type R
DP015RS, DP030RS, DP045RS, DP060RS
DP030RD, DP060RD, DP090RD,
DP045RT, DP090RT
DP075RS, DP090RS
Screw M6 M8
WARNING
CAUTION
