10.12 Power Unit Energization Setting
DP Series/DP Series Type R
283
10.12 Power Unit Energization Setting
The power consumption can be decreased by decreasing the number of the power units in
operation according to the load capacity. Each power unit can be enabled (energized)/disabled (not
energized) separately. (1.5 kVA or 1.5 kW/power unit)
Single-phase model and Single-phase output of Multi-phase model
DP series
015S 030S
045S
045M
060S 075S
090S
090M
105S 120S
DP series Type R
015RS 030RS 045RS 060RS 075RS 090RS
Number of units 1 2 3 4 5 6 7 8
Energizing setting
*53
No Yes
*53: Can be set for only a model with more than one unit.
Polyphase model and Polyphase output of Multi-phase model
DP series
030D 060D 090D 120D
045T
045M
090T
090M
DP series Type R
030RD 060RD 090RD 045RT 090RT
Number of units
(per phase)
1 2 3 4 1 2
Energizing setting
*54
No Yes No Yes
*54: Can be set for only a model with more than one unit per phase.
