2.2 About Installation Environment
DP Series/DP Series Type R
11
2.2 About Installation Environment
To use safely and maintain the reliability, take the followings into consideration:
Install the product where the exhaust heat will not damage surroundings.
This product performs forced air cooling using a fan. Keep the front and rear, on which the air
inlet and outlet are located, away from the wall at least 50 cm to secure air circulation.
This product exhausts the heat from the air outlet on the rear. Do not place heat-sensitive
objects around the outlet.
If you install the product in a closed narrow room, air conditioning equipment is required. The
heat value of DP series is shown in Table 2-2. The heat value of DP series Type R is shown in
Table 2-3.
Table 2-2 Heat Value of DP series
Model Rated output Heat value
Single-phase
DP015S 1.5 kVA 0.5 kW 430 kcal/h
DP030S 3 kVA 0.9 kW 780 kcal/h
DP045S 4.5 kVA 1.4 kW 1210 kcal/h
DP060S 6 kVA 1.8 kW 1550 kcal/h
DP075S 7.5 kVA 2.3 kW 1980 kcal/h
DP090S 9 kVA 2.7 kW 2320 kcal/h
DP105S 10.5 kVA 3.2 kW 2760 kcal/h
DP120S 12 kVA 3.6 kW 3100 kcal/h
Single-phase
three-wire
DP030D 3 kVA 0.9 kW 780 kcal/h
DP060D 6 kVA 1.8 kW 1550 kcal/h
DP090D 9 kVA 2.7 kW 2320 kcal/h
DP120D 12 kVA 3.6 kW 3100 kcal/h
Three-phase
DP045T 4.5 kVA 1.4 kW 1210 kcal/h
DP090T 9 kVA 2.7 kW 2320 kcal/h
Multi-phase
DP045M 4.5 kVA 1.4 kW 1210 kcal/h
DP090M 9 kVA 2.7 kW 2320 kcal/h
Note: Estimate at power input single-phase 200 V or three-phase three-wire 200 V or
three-phase four-wire 380 V (phase voltage 220 V), rated output.
