1. Outline
PROGRAMMABLE AC POWER SOURCE
4
Table 1-3 Combination of DP series
DP015S DP030S DP045S DP060S DP075S DP090S DP105S DP120S
DP015S
1P3W: 3.0 kVA
3P4W: 4.5 kVA
× × × × × ×
DP030S
1P3W: 6.0 kVA
3P4W: 9.0 kVA
× × × × × ×
DP045S
× ×
1P3W: 9.0 kVA
3P4W: 13.5 kVA
× × × ×
DP060S
× ×
1P3W: 12.0 kVA
3P4W: 18.0 kVA
× × × ×
DP075S
× × × ×
1P3W: 15.0 kVA
3P4W: 22.5 kVA
× ×
DP090S
× × × ×
1P3W: 18.0 kVA
3P4W: 27.0 kVA
× ×
DP105S
× × × × × ×
1P3W: 21.0 kVA
3P4W: 31.5 kVA
DP120S
× × × × × ×
1P3W: 24.0 kVA
3P4W: 36.0 kVA
Table 1-4 Combination of DP series Type R
DP015RS DP030RS DP045RS DP060RS DP075RS DP090RS
DP015RS
1P3W: 3.0 kVA
3P4W: 4.5 kVA
× × × ×
DP030RS
1P3W: 6.0 kVA
3P4W: 9.0 kVA
× × × ×
DP045RS
× ×
1P3W: 9.0 kVA
3P4W: 13.5 kVA
× ×
DP060RS
× ×
1P3W: 12.0 kVA
3P4W: 18.0 kVA
× ×
DP075RS
× × × ×
1P3W: 15.0 kVA
3P4W: 22.5 kVA
DP090RS
× × × ×
1P3W: 18.0 kVA
3P4W: 27.0 kVA
Table 1-5 Combination of DP series and DP series Type R
DP015S DP030S DP045S DP060S DP075S DP090S DP105S DP120S
DP015RS
1P3W: 3.0 kVA
3P4W: 4.5 kVA
× × × × × ×
DP030RS
1P3W: 6.0 kVA
3P4W: 9.0 kVA
× × × × × ×
DP045RS
× ×
1P3W: 9.0 kVA
3P4W: 13.5 kVA
× × × ×
DP060RS
× ×
1P3W: 12.0 kVA
3P4W: 18.0 kVA
× × × ×
DP075RS
× × × ×
1P3W: 15.0 kVA
3P4W: 22.5 kVA
× ×
DP090RS
× × × ×
1P3W: 18.0 kVA
3P4W: 27.0 kVA
× ×
Note: In case of combination of Table 1-3 and that of Table 1-5, an error message (ID: 53 Power Unit
DCPS Overvoltage) may be displayed and the output may be turned off when the reverse power
flow is occurring.
1.3 Features
 Reverse power flow
DP series Type R supports the reverse power flow. User does not need to consult with the power
companies about power system interconnection because DP series Type R processes the reverse
power internally and does not regenerate to the power system when the reverse power flow is
occurring. Also, DP series Type R supports sink current in DC mode. User can use DP series Type R
for testing equipment such as bidirectional converters.
