4.1 Burst oscillation
WF1946B 4-7
(4) Set MARK cycle
① Use the
and keys to produce the following display (MARK flashes).
１．０ ｃｙｃｌｅ
ＴＲＩＧ：ＴＹＰＥ ＳＯＵＲＣＥ ＤＥＬＡＹ ＭＡＲＫ
4
② Press the
ENTER
key.
Set the mark cycles with the keypad or
MODIFY
dial (0.5 cycle units).
In this example, the setting is 2.0 cycles.
③ After setting, press the
EXIT
key once to release mark cycle setting.
(5) Set STOP-LEVEL
① Use the
and keys to produce the following display (STOP-LEVEL flashes).
ＯＦＦ
ＴＲＩＧ：
3
ＳＴＯＰ―ＬＥＶＥＬ
② Press the
ENTER
key.
Turn the
MODIFY
dial to produce the following display (ON flashes).
ＯＮ ０．００ ％
ＴＲＩＧ：
3
ＳＴＯＰ―ＬＥＶＥＬ
③ Press the
key, then set the stop level with the keypad or
MODIFY
dial.
In this example, the setting is -50 %.
The stop level is the percentage with respect to the maximum positive (+100 %) and negative (-100 %)
amplitude.
④ After setting, press the
EXIT
key to release the setting mode.
