3-43
3
STN
Once the data enough to calculate the
Station coordinates are obtained, its
standard deviation screen will be
displayed.
Press [ESC] to return to the last
measurement screen.
Press [1] to add more direction to enhance
the accuracy of your resection.
When you are satisfied with the result,
press [4] or [ENT] to record the station
through ST input & Select BS screen.
For [3:View] functionality, please turn to
the next page for details.
σＮ： ０．０１９３
σＥ： ０．００８４
σＺ： ０．０２７０
Ａｄｄ ＤＳＰ Ｖｉｅｗ ＲＥＣ
･In 2-Pt Resection, one point is distance measured while the other is
angle measured, the sigma values will not be available.
･When the known PT has a Z-coordinate, the Stn-Z will be given for
your reference even without a distance measurement. If you take a
distance measurement to any point, the Stn-Z will be calculated by
that measurement, not from any angle measurements.
Ｎ： ２８０．４１９３
Ｅ： －７．０８１４
Ｚ： １６．０２７０
Ａｄｄ ＤＳＰ Ｖｉｅｗ ＲＥＣ
[2:DSP]
[2:DSP]
