NKT Photonics SuperK COMPACT User Manual

Connecting the laser to a CONTROL PC
46
Procedure 1 Connecting a PC to the laser using a USB cable
Action
1 Using a USB Type A-B cable, connect an available USB Type A port of the CONTROL PC
to the laser’s USB Type B port.
i
i. The PC can also be connected by connecting its serial port using a standard RS232 serial
cable to the RS232 port on the laser.
2 Connect power to the Laser – see Connecting power on page 77.
3 If necessary, wait for the Windows device manager to install the USB drivers for the
connection.
4 Launch the CONTROL software by either:
• clicking on Windows – Start – Programs – NKT Photonics –CONTROL
– or –
• double clicking the CONTROL shortcut on the desktop
5 The CONTROL window opens.
Click on the Connect button in
the upper left region of the
window.
6 CONTROL automatically scans
for any connect lasers and
accessories available on both
COM and configured Ethernet
ports.
7 To manage the laser, click on
the SuperK COMPACT laser
icon from the Device Selector
list.
