NKT Photonics SuperK COMPACT User Manual

99
E Accessories
This appendix provides a brief overview of the accessories available for your
laser. Table 19 lists the accessories and their functions and provides a link to
descriptions of the SuperK COMPACT advanced accessories.
Table 19 SuperK COMPACT accessories
Advanced accessories Function Part number
VARIA Variable bandpass filter A301-100-000 “SuperK VARIA” on page 100
SELECT Multi-wavelength AOTF A203-XXX-000 or
A203-XXX-010
“SuperK SELECT” on page 101
LLTF Narrow laser line filter A371-500-000 or
A371-200-000
“SuperK LLTF” on page 103
SPLIT Broadband filter A102-200-000 or
A102-500-000
“SuperK SPLIT” on page 104
CONNECT Delivery fiber A401-000-000 or
A401-200-000 or
A401-500-000
“SuperK CONNECT” on page 105
Other accessories
Polarizing Lock Ring Aligns and positions the
collimator properly in an
accessory optical input
M0073-0002-00 “Polarization spacer” on page 106
Connect Holder Optical table mount for
Connect Accessory
000-000-003
Collimator Holder Receptacle for laser or
accessory collimator
M0002-4041-00
External Filter Holder Beam path 1” filter mount
for any filter accessory.
A000-000-004
TL30 mm Adapter Accessory adapter for
Thorlabs 30 mm cage
system
A000-000-005
USB Adapter Kit USB to RS485 adapter,
used to connect
accessories to a PC
A911-100-103
Key Spare key for the laser’s
key switch
A911-100-009
External Bus Defeater Spare bus defeater for the
External Bus ports
A911-100-007
Door Interlock Connector Spare Lemo connector
assembly for the door
interlock circuit.
A911-100-005
Bus Cable Used to connect the laser
to any accessories.
A911-100-006
USB Cable Spare Type A to B USB
cable
A911-100-004
BNC Cable Used to connect External
Control Input or Pulse
Output.
A911-100-008
