CONTROL menu

Figure 33 Extensions Overview

Note: To show a short description of the release notes as seen in Figure 33, hover

the mouse pointer over the “Release notes” text

The PubCompactLib.dll details highlighted in Figure 33 shows the version of the

.dll file (1.1.2.303), the included extensions and which module types they support.

Note: Multiple extensions for a wide range of NKTP lasers types are typically in-

stalled when using the default installation of CONTROL.

Guide Overview3
