69
Device monitor
SysType The system type, default 0 – can be used to describe system variants
and is read from the module.
Name The name of the connected device module.
P/N The device module part number.
Mode The mode or status of the connected module: connected,
disconnected, or disabled
Status bits The actual status bits read from the connected module.
Error code The actual error code read from the connected module.
Access Protected/Locked status of the module.
FW Ver. The device module’s firmware release date.
Module Serial The serial number of the device module
PCB Serial The device module’s printed circuit board serial number
PCB Ver, The version of the device module’s printed circuit board.
Sp. Cap/ The module speed capability in bits per second as read from the
module – Values: 0=(default) 115200, 1=230400, 2=460800, 3=921600
Pri Ext Primary extension/GUI loaded for this module. Hover over the icon to
list more details – Note that there can only be 1 primary.
Fast Log 0%-100% collected. Note only if the module has a fast log and only
internal modules have fast and slow logs.
Slow Log 0%-100% collected. Note only if the module has a slow log.
Mainboard Log 0%-100% collected. Note only if the module has a main log. Only main
boards have a main and system logs.
System Log 0%-100% collected. Note only if the module has a system log. Only main
boards have a main and system logs.
Timeout Time in milliseconds since the last telegram was received from the
device module.
Nack Total number of negative acknowledgments received from the device
module.
CRC Total number of received telegrams with CRC failures
COM Total number of communication errors with framing or protocol errors.
Hover over the icon to list more details.
Busy Total number of busy responses from the module. Busy responses
occur when the module receives a message but cannot process it due
to its current work load.
Parameter Description
