Nordson Universal Series User Manual

Electrical System
11-7
Part 1079832_04
E 2015 Nordson Corporation
Connecting Heated Air Manifold Cordsets
Connect heated air manifold cordsets as appropriate for your application.
Refer to Table 11‐2 and Figure 11‐7 for two typical installation configurations.
Table 11-2 Typical Heated Air Manifold Cordset Connections
Item in
Figure 11-7
Component Connect to...
1
One heated air manifold
cordset
Extension cable (item 2)
2 Extension cable Cordset (item 1) and adapter cable (item 3)
3 Adapter cable Extension cable (item 3) and electrical receptacle on melter
4
Two heated air manifold
cordsets
Extension cables (item 5)
5 Extension cables Cordsets (item 4) and splitter cable (item 6)
6 Splitter cable Extension cables (item 5) and electrical receptacle on melter
(item7)
