Nordson Universal Series User Manual

Electrical System
11-24
Part 1079832_04
E 2015 Nordson Corporation
Technical Data
Electrical Specifications
Refer to the identification plate on the applicator for voltage and wattage
information. For the location of the identification plate on your applicator,
refer to the reference drawing of the applicator in Applicator‐Specific
Reference Drawings in Section 8, Parts.
T‐Style Cordset Wiring Diagrams
These wiring diagrams are provided for your reference as needed during
troubleshooting activities. Refer also to Applicator‐Specific Reference
Drawings in Section 8, Parts, for wiring diagrams specific to your applicator.
T‐Style Cordset Pin Positions
3
4
5
2
1
HEATER
HEATER
RTD
RTD
GROUND
12
3
5
4
Figure 11-20 T-style cordset pin positions
