Description
2-1
Part 1079832_04
E 2015 Nordson Corporation
Section 2
Description
WARNING! Allow only personnel with appropriate training and experience to
operate or service the equipment. The use of untrained or inexperienced
personnel to operate or service the equipment can result in injury, including
death, to themselves and others, and damage to the equipment.
Introduction
Nordson high‐speed Universal Series spray applicators apply thermoplastic
hot melt adhesive to various products. The applicators are configurable,
which means each is constructed according to the specific choices made
when the applicator was ordered. The key parts of two typical applicators (a
single‐module and a multi‐module) are shown in Figures2‐2 and 2‐3.
Figure 2-1 Single-module high-speed Universal Series spray applicator
