Module
9-1
Part 1079832_04
E 2015 Nordson Corporation
Section 9
Module
WARNING! Allow only personnel with appropriate training and experience to
operate or service the equipment. The use of untrained or inexperienced
personnel to operate or service the equipment can result in injury, including
death, to themselves and others, and damage to the equipment.
Introduction
This section provides troubleshooting, repair, parts, and specification
information for applicators with Universal Speed‐Coat modules. The
Universal Speed‐Coat module, either directly or through the use of a nozzle
adapter, accurately applies adhesive on high‐speed intermittent production
lines in a variety of spray applications, including Controlled Fiberization (CF),
Summit, SureWrap, Control Coat, and Signature applications. The Universal
Speed‐Coat module is installed on the applicator through the use of a
Universal adapter. Figure9‐1 shows the key components of the Universal
Speed‐Coat module parts family.
1
2 3 5
6
4
7
8
9
Figure 9-1 Universal Speed-Coat module and associated adapters and nozzles
1. Speed‐Coat control module with
boosted solenoid valve
2. Speed‐Coat control module with
non‐boosted solenoid valve
3. Bead adapter (for bead nozzles)
4. CF adapter (for CF disk and
unibody nozzles)
5. Universal CF nozzle
6. Summit nozzle
7. SureWrap nozzle
8. Control Coat nozzle
9. Signature nozzle, intermittent
Note: The bead adapter is used in non‐spray applications, which are not covered by this manual. For more information on
the use of this adapter, contact your Nordson representative.
Note: No adapter is required for Universal CF, Summit, SureWrap, Control Coat, and Signature nozzles.
