Control Module With Boosted Solenoid Valve Parts
See Figure 9‐9.
Item Part Description Quantity Note
— 7162040 Control module, SC, 24V booster cpl. fix —
1 7162039 S Control module SC basic assy booster fix 1
1A 7162021 S S Cylinder S.C. w/sensor-drill f.shaped g. 1
2 7162043 S S Cylinder SC screwed flange valve D20/14 1
16 423855 S S Allan head cap screw M4x55 DIN912 SST 2
25 635926 S S O-ring 17x1.5 Viton 2
29 251755 S S O-ring 7x1,5 Viton 1
50 7103652 S S Plug,sensor SC w. O-ring 1
3 7157157 S Fast switch valve SC 24V booster 80°C 1
12 396252 S Insulation plate SC 1
20 401899 S Valve socket 2+PE 90° LED 24/48VDC 9,4mm 1
90 7113424 S Gasket for fast switch valve 1
