Electrical System
11-5
Part 1079832_04
E 2015 Nordson Corporation
Cordset Connection
Cordsets must be properly connected to hoses and/or splitter and extension
cables to supply power to the applicator. This part of Section 11 provides
cordset connection procedures for an installation in which adhesive manifold
cordsets are connected to hose connectors and to extension and adapter
cables and in which heated air manifold cordsets are connected to heated air
manifold extension and splitter or adapter cables, which is the recommended
configuration. If you need assistance with cordset installation, contact your
Nordson representative.
NOTE: Normally, the hose, cordset, and cable configuration of your system
will have already been determined by you and your Nordson representative.
If you need to change the configuration, contact your Nordson representative
for assistance. Splitter, adapter, and extension cable part numbers are
provided in Parts at the end of this section.
WARNING! Risk of personal injury or death. Allow only qualified personnel to
perform electrical installation, troubleshooting, or repair procedures. Before
performing any electrical procedure, review Section 1, Safety, and
disconnect and lock out electrical power to the system.
Preparing to Connect Cordsets
1. If the system is in operation, relieve system pressure. Refer to Relieving
System Pressure in Section 10, Filter.
2. Disconnect and lock out electrical power to the system.
