Nordson Universal Series - Applicator-Specific Reference Drawings; Location of Other Parts Lists

Parts
8-2
Part 1079832_04
E 2015 Nordson Corporation
Applicator‐Specific Reference Drawings
For a parts list specific to your applicator, refer to the reference drawings and
bill of materials provided with this manual. The item numbers on reference
drawings correspond to the numbers in the Item column on the bill of
materials. If you have any questions about how to read the reference
drawings or the bill of materials, contact your Nordson representative.
Location of Other Parts Lists
Because applicator configurations vary, most of the parts lists in this manual
are located in Sections 9–11, which are specific to your applicator. Table8‐1
shows the location of the other parts lists in this manual.
Table 8-1 Location of Other Parts Lists
Parts Lists for... Are located in...
Modules (including solenoid
valves) and nozzles
Section 9, Module
Filter Section 10, Filter
Cordsets, splitter and extension
cables, heaters, sensors (RTDs or
thermocouples), and thermostats
Section 11, Electrical System
