Electrical System
11-20
Part 1079832_04
E 2015 Nordson Corporation
T‐Style Extension Cables
See Figure 11‐16. These extension cables can be used to connect splitter
cables and/or hose and applicator cordsets to the electrical receptacles on
the melter.
Part Description Note
117123 Extension cable, T‐style, low‐power applicator cordset, 1.83 m (6 ft)
164045 Extension cable, T‐style, low‐power applicator cordset, 3.05 m (10 ft)
108946 Extension cable, T‐style, low‐power applicator cordset, 4.88 m (16 ft)
135972 Extension cable, T‐style, low‐power applicator cordset, 7.32 m (24 ft)
753462 Extension cable, T‐style, low‐power applicator cordset, 9.14 m (30 ft)
754505 Extension cable, T‐style, low‐power applicator cordset, 10.66 m (35 ft)
756195 Extension cable, T‐style, low‐power applicator cordset, 12.19 m (40 ft)
150837 Extension cable, T‐style, low‐power applicator cordset, 15.24 m (50 ft)
152813 Extension cable, T‐style, low‐power applicator cordset, 18.29 m (60 ft)
Figure 11-16 T-style low-power applicator cordset extension cable
