Nozzle Part Numbers
For nozzle part numbers, refer to the nozzle‐specific manuals available at
emanuals.nordson.com, or contact your Nordson representative for
assistance.
Recommended Spare Parts and Supplies
For a general spare parts and supplies list, refer to Recommended Spare
Parts and Supplies in Section8, Parts.
Part Description Note
7162040 Control module SC 24V booster cpl. fix (control module with boosted solenoid valve)
7157157 S Fast switch valve SC 24V booster 80°C
7113424 S Gasket for fast switch valve
635926 S O-ring 17x1.5 Viton (2 required for the Speed‐Coat control module)
251755 S O‐ring 7 x 1.5 Viton (1 required for the Speed‐Coat control module)
423855 S Allan head cap screw M4x55 DIN912 SST (2 required to secure the control module)
7162060 Control module SC 24/48V ES70 cpl.fix (control module with standard solenoid valve)
460246 S Solenoid valve 3/2ways 24V/2,5W NC flg.
219371 S Seal,solenoid valve 3/2ways 24V 2,5W FL (1 required for the Speed‐Coat control module)
635926 S O-ring 17x1.5 Viton (2 required for the Speed‐Coat control module)
251755 S O-ring 7x1.5 Viton (1 required for the Speed‐Coat control module)
423855 S Allan head cap screw M4x55 DIN912 SST (2 required to secure the control module)
250006 S Allan head cap screw M3x30 DIN912 SST (2 required to secure the solenoid valve)
1049289 Screw, adapter mounting, 10‐32 x 0.75 in., stainless‐steel (2 required to secure the
Universaladapter)
940111 O‐ring, Viton, 0.301 ID x 0.070 W in. (3 required for the back of the Universal adapter)
1049300 Kit, nozzle‐retaining clamp assembly
466428 Fitting, module‐actuating air supply, straight
1055967 Fitting, module‐actuating air supply, 90‐degree
1108372 Lubricant, O-ring, NSF-H1, food grade (for O‐rings)
1108371 Lubricant, Never-Seez, NSF-H1, food grade (for screw threads)
394769 Grease, high‐temperature, GLS 595/N2, can, 10 g (for the Speed‐Coat control module
mounting screws and O‐rings)
783959 Grease, high‐temperature, GLS 595/N2, tube, 250 g (for the Speed‐Coat control module
mounting screws and O‐rings)
