Nordson Universal Series User Manual

Module
9-14
Part 1079832_04
E 2015 Nordson Corporation
Control Module With Standard Solenoid Valve Parts
See Figure 9‐10.
Item Part Description Quantity Note
— 7162060 Control module, SC, 24/48V, ES70 cpl.fix —
1 7162059 S Control module SC 24/48V ES70 basic, assy 1
1A 7173123 S S Cylinder cover SC ES70 fix w/sensordrill 1
2 7162043 S S Cylinder SC screwed flange valve D20/14 1
25 635926 S S O-ring 17x1.5 Viton 2
29 251755 S S O-ring 7x1,5 Viton 1
40 204211 S S Silencer M5x3,9 L=8,8 SK=8 1
50 7103652 S S Plug,sensor SC w. o-ring 1
3 460246 S Solenoid valve 3/2ways 24V/2,5W NC flg. 1
12 7103655 S Insulation plate SC ES70 1
20 401899 S Valve socket 2+PE 90° LED 24/48VDC 9,4mm 1
60 250006 S Allan head cap screw M3x30 DIN912 SST 2
90 219371 S Seal,solenoid valve 3/2ways 24V 2,5W FL 1
