Nordson Universal Series User Manual

Electrical System
11-25
Part 1079832_04
E 2015 Nordson Corporation
T‐Style Cables
1
56
2 34
8
86
4
5
1
2
3
12
5
9
11
HOSE/APPLICATOR HEATER
HOSE/APPLICATOR HEATER
HOSE/APPLICATOR RTD
HOSE RTD
GROUND
8
4
10
HOSE HEATER
6
HOSE HEATER
4
8
6
6
4
8
5
HOSE HEATER
HOSE RTD
HOSE RTD
GROUND
HOSE HEATER
HOSE RTD
HOSE RTD
HOSE HEATER
5
GROUND
HOSE HEATER
GROUND A
GROUND B
HOSE RTD
86
4
5
Figure 11-21 T-style splitter cable for two hose cordsets
Note: The control system will display the hose plugged into the one of these connectors as an applicator zone.
