Electrical System
11-26
Part 1079832_04
E 2015 Nordson Corporation
T‐Style Cables (contd)
1
56
3
4
8
5
4
2
3
1
5
4
2
3
1
11
9
12
1
3
4
5
6
8
2
2
5
3
1
3
2
5
1
2
9
11 12
APPLICATOR HEATER
APPLICATOR HEATER
APPLICATOR HEATER
APPLICATOR HEATER
APPLICATOR HEATER
APPLICATOR HEATER
APPLICATOR RTD
APPLICATOR RTD
APPLICATOR RTD
APPLICATOR RTD
HOSE/APPLICATOR RTD
APPLICATOR RTD
GROUND
GROUND
GROUND
HOSE/APPLICATOR RTD
HOSE/APPLICATOR HEATER
HOSE/APPLICATOR HEATER
Figure 11-22 T-style splitter cable for two low-power applicator cordsets
Note: The control system will display the applicator plugged into the HG connector as a hose zone.
