Electrical System
11-27
Part 1079832_04
E 2015 Nordson Corporation
5
4
2
3
1
3
5
4
2
1
APPLICATOR HEATER
APPLICATOR RTD
APPLICATOR RTD
GROUND
1
5
3
2
1
2
3
4
5
6
8
10
11
APPLICATOR HEATER
APPLICATOR RTD
HOSE/APPLICATOR RTD
GROUND
9
12
APPLICATOR HEATER
APPLICATOR HEATER
Figure 11-23 T-style low-power applicator cordset extension cable
