Nordson Universal Series - Torque Specifications

Module
9-19
Part 1079832_04
E 2015 Nordson Corporation
Torque Specifications
These torque specifications are also stated within the appropriate
procedures.
Item Torque Specification
Speed‐Coat control module
mounting screws
2.7NSm(24in.‐lb)
Nozzle‐retaining clamp screw 2.8 NSm (25 in.‐lb)
CF disk nozzles 3.4 NSm (30 in.‐lb)
CF unibody nozzles 0.6 NSm (5 in.‐lb)
