Nordson Universal Series User Manual

Electrical System
11-21
Part 1079832_04
E 2015 Nordson Corporation
M‐Style Splitter and Adapter Cables
See Figure 11‐17. These splitter and adapter cables can be used to connect
the cordsets on hoses and applicators to the electrical receptacles on the
melter. In most cases, extension cables will be needed.
Item Part Description Quantity Note
1 291218 Splitter cable, M‐style, 2 heated air manifold
cordsets, 0.3m
AR
2 291215 Splitter cable, M‐style,1 adhesive manifold cordset
and 1 heated air manifold cordset, 0.3 m
AR
3 291217 Splitter cable, M‐style, 2 adhesive manifold
cordsets, 0.3m
AR
4 291223 Adapter cable, M‐style, 1 heated air manifold
cordset, 0.3m
AR
5 291216 Adapter cable, M‐style, 1 adhesive manifold
cordset, 0.3m
AR
6 413913 Splitter cable, M‐style, 2 hose cordsets, 0.3m AR
AR: As Required
1 2 3 4 5 6
Figure 11-17 M-style splitter and adapter cables
