Module
9-18
Part 1079832_04
E 2015 Nordson Corporation
Technical Data
Applicator Specifications
Table 9‐4 provides specifications for a high‐speed Universal applicator with
Speed‐Coat modules. Refer to Applicator‐Specific Reference Drawings in
Section 8, Parts, for the following information about your applicator:
S applicator dimensions
S cordset style
S number and orientation of filters
S number of modules
S type and number of solenoid valves
Table 9-4 High-Speed Universal Applicator Specifications
Item Specification
Operating temperature
70−200 _C (160−392 _F)
Working hydraulic pressure 13.8−55.2 bar (200−800 psi)
Maximum hydraulic pressure 89.6 bar (1300 psi)
Maximum hydraulic flow (per module) 110 g/min at 10,000 cps, 14 g/m
2
at 300 m/min
Module-actuating air pressure 4 bar (58 psi) minimum
5−6 bar (73−88 psi) recommended
Maximum pattern air flow (per 25-mm
pattern)
1.0 scfm at 191 _C (375 _F);
1.5 scfm at 177 _C (350 _F)
Adhesive pattern capability High‐speed intermittent
Speed-Coat control module maximum
ambient temperature
60 _C (140 _F)
Solenoid valve supply voltage Solenoid valve with boost: 24 VDC only (without spiked output)
Solenoid valve without boost: 24 VDC
Boosted solenoid valve maximum
operating temperature
82 _C (180 _F)
NOTE: For additional information on the capabilities of Universal modules and nozzles, contact your
Nordson representative to obtain the following product literature: Product Comparison: Universal Modules
and Product Comparison: Universal Spray Nozzles.
