Parts
8-6
Part 1079832_04
E 2015 Nordson Corporation
Recommended Spare Parts and Supplies
The following tables provide part numbers for commonly used spare parts
and supplies. A recommended stocking quantity is provided in the Quantity
column of the recommended spare parts table, but you should base your
parts‐stocking decisions on your specific operational needs. The quantity of
each item you stock will vary depending on the number of hours you operate
each day, the size and number of applicators you have, and the number of
modules installed on each applicator.
Table 8-2 Recommended Spare Parts
Item Part Description Quantity
Modules
See Note A Replacement modules 1
See Note B Module mounting screws, O‐rings, and other applicable spare
parts and tools
AR
Filter
1049206 Replacement filter assemblies 1
1049208 S Replacement filter screens 1
940223 S Replacement filter O‐rings 6
1058544 S Tool, Universal, filter removal (see Note C) 1
Nozzles
See Note A Replacement nozzles 2
901915 Kit, nozzle cleaning, small orifice 1
231100 Kit, nozzle cleaning, large orifice 1
Solenoid valves See Note A Replacement solenoid valve assemblies 1
Electrical system
See Note A Replacement adhesive manifold cordset assemblies 1
See Note A Replacement heated air manifold cordset assemblies 1
See Note A Replacement heaters for adhesive and heated air manifolds 2
See Note A Replacement sensors for adhesive and heated air manifolds 2
139671 Tool, pin crimping 1
100586 Tool, pin extraction 1
NOTE A: Refer to the applicator‐specific reference drawings to determine the part number for this item. Refer also to
Parts in Sections 9–11 as appropriate.
B: Refer to Recommended Spare Part and Supplies in Section 9, Module.
C: This tool has a filter‐removal end and a nut‐driver end and can be used for all applicator‐related service
activities. Refer to Recommended Spare Parts and Supplies in Section 10, Filter, for an illustration of the
tool.
AR: As Required
Table 8-3 Recommended Supplies
Part Description Note
1120201 Lubricant, O-ring, NSF-H1, 10 ml tube (for lubricating O‐rings)
1108371 Lubricant, Never-Seez, NSF-H1, food grade (for lubricating threads)
165415 Lubricant, heater (for lubricating heaters)
900298 Compound, heat‐sink, 5 oz tube (for lubricating sensors)
