Nordson Universal Series User Manual

Module
9-3
Part 1079832_04
E 2015 Nordson Corporation
2
1
6
7
5
4
3
Figure 9-3 Key parts of a Universal Speed-Coat module (Speed-Coat module with
boosted solenoid valve shown installed on a single-module high-speed
applicator assembly)
1. Speed‐Coat control module (module with
boosted solenoid valve shown)
2. Module mounting screw
3. Applicator body
4. Universal nozzle clamp assembly
5. Nozzle‐retaining clamp screw
6. Nozzle O‐ring
7. Nozzle
